AP Pipe Cutter
The AP Pipe Cutters are specifically designed for PE, PPR and PVC pipes from 16mm – 630mm ( see drip irrigation cutters for diameters 6mm – 32mm). Our cutters are shipless for PE and PPR pipes up to 250mm in diameter and comes with a chamfer option for PVC pipes ranging from 40mm – 630mm.
Our cutters are in compliance with modern safety standards and manufactured to operate in complete synchronization with your extrusion line. The trolley movement is driven either by a servo motor or by pneumatics and the pipe cutting diameter does not require mechanical adjustment but, can be set using the PLC control system.
Models Specification
| Model | Pipe Dia (mm) | Max Cutting Thickness | Cutting Speed (m/min) |
| SINEX 75 | 16 – 75mm | PE: 15mm PVC: 4mm | 30 m/min |
| SINEX 160 | 50 – 160mm | PE: 22mm PVC: 10mm | 22 m/min |
| SINEX 250 | 50 – 250mm | PE: 28mm PVC: 25mm | 12 m/min |
| SINEX 400 | 63 – 400mm | PE: 42mm PVC: 25mm | 8 m/min |
| SINEX 630 | 160 – 630mm | PE: 60mm PVC: 25mm | 4 m/min |
